Product Details
Place of Origin: Hangzhou, CHINA
Brand Name: Zoyo
Certification: ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Model Number: ZY006901
Payment & Shipping Terms
Minimum Order Quantity: Flexible MOQ
Price: $2~$500 per piece
Packaging Details: CUSTOMIZED
Delivery Time: 3-4 weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5k-20k pieces per day
Size(inch): |
0.69 |
Resolution: |
96*16 |
Active Area(mm): |
17.60*3.18 |
Operating Temperature: |
-40℃～70℃ |
Size(inch): |
0.69 |
Resolution: |
96*16 |
Active Area(mm): |
17.60*3.18 |
Operating Temperature: |
-40℃～70℃ |
| GENERAL SPECIFICATIONS | ||||
| Item | Specification | Unit | Note | |
| Screen Size | 0.69 | |||
| Resolution | 96*16 | pixels | ||
| Operating Temperature | ‐40℃~70℃ | |||
| Storage Temperature | ‐40℃~85℃ | |||
| Module Size | Horizontal (H) | 26.30 | mm | typ |
| Vertical (V) | 8.00 | |||
| Thickness (T) | 1.2 | |||
| Active Area | Horizontal | 17.60 | mm | |
| Vertical | 3.18 | |||
| Interface Type | I2C | |||
| Application | Smart bracelet, ETC, electronic cigarette | |||
| Kind Tips: More details please contact us for products' specifications | ||||
The difference between PMOLED and AMOLED
| Feature | PMOLED | AMOLED |
| Matrix Type | Passive Matrix | Active Matrix |
| Control Mechanism | Sequential control of rows/columns | Individual pixel control via TFTs |
| Resolution | Lower | Higher |
| Brightness/Contrast | Good, but less uniform | Superior brightness and contrast |
| Refresh Rate | Lower, potential flickering | Higher, suitable for dynamic content |
| Power Consumption | Higher for larger/bright content | More efficient, especially with dark content |
| Complexity/Cost | Simpler, cheaper | More complex, more expensive |
| Typical Applications | Small, simple displays | High-end, high-resolution displays |
